THRU
119.00 €
Price without VAT & taxes
THRU is a utility module designed for signal distribution and precise voltage processing within your Eurorack system.
Designed for live performance and Eurorack patching, it can be used in conjunction with the TONE module or as a standalone module.
Operating Modes:
1. Expansion Mode (with TONE): When connected to the TONE module, THRU
extends the system to support up to 12 voices of polyphony.
2. Standalone Mode: In standalone operation, THRU provides the following functions:
● Active Multiple: Routes the CV IN signal to 8 buffered outputs.
● Voltage Summing: Adds the CV IN signal to each of the 8 inputs independently.
Technical Features:
● High Precision Summing: Ensures accurate voltage addition, maintaining stable and
consistent transposition across all channels.
● Independent Channels: Each input/output pair operates independently.
All channels share a common transposition voltage derived from CV IN.
● Normalization: When an input is not connected, it is internally routed to the signal
from TONE Input 1 or to a fixed reference voltage.
● Visual Feedback: Two LED indicate the voltage level and polarity of the CV IN signal.
Technical details
● Gain error between In and Out: maximum 0,1%
● Outputs buffered with a very low offset buffer
● Power requirement +/-15 mA @ +/- 12V.
● Polarised power header and protection against reverse polarity.
● Eurorack 6 HP wide, maximum depth 26mm.
